Send InquiryHeat Setting Machine
Product Details:
- Type Automatic
35000.00 - 48500.00 USD ($)
X
Heat Setting Machine Price And Quantity
- 35000.00 - 48500.00 USD ($)
- 1 Set
Heat Setting Machine Product Specifications
- Automatic
Heat Setting Machine Trade Information
- Tianjin Port
- Letter of Credit (L/C) Western Union Telegraphic Transfer (T/T)
- 100sets Per Year
- 30 Days
- Standard Packages
- Eastern Europe Africa Middle East South America Asia
Product Description
Introduction
- This Heat Setting Machine is used for processing of tubular chemical knitted fabric, The machine makes synthetic and mixed fabric to obtain stable size with stainless steel roller.
- The fabric is heated in the heating chamber and get cool process when getting out of machine.
- We can offer following two machines according to the width of the heating chamber: DGDX2400, DGDX3800.
- DGDX2400 machine has two work modes: double and single.When processing a narrow fabric. the double mode is adopted; When processing the wider fabric, the single mode is adopted. We can also offer you three-way mode to work.
- DGDX3800 machine adopt dual driving control mode and working mode can be designed by your requirement.
- You can customize the mercy, volume, cutting knives, and doubles.
- We can offer the following five different machine according to the normal heat source:electricity, thermal oil, natural gas.
- We make sure that we can deal with all process better in terms of energy saving and consumption,
- We will try to save cost for customer and make you get profit from this.
Basic Info & Technical Data
| Main Matching Fabric | Tubular chemical fiber |
| Max. Working Width: | DGDX2400 Working width: 1600mm |
| Supporting plate | Manually regulate |
| Machine Speed | 3－20m/min |
| Chamber Width | 2400mm |
| Power Supply | 380V·3P·50HZ |
| Main Color | Blue/Customize |
| Weight of Machine | DGDX2400 Weight: 6T |
| Drive installed capacity | DGDX2400 : 14.15kw |
| Heat-setting Type | Hot air circulating |
| Fabric Breadth control | Manually regulate |
| Driving type | Independently drive(single) |
| Temp. control type | Auto temp. Control |
| Compressed air | 0.35-0.6MPa |
| Dimension | DGDX2400 : 5700*4100*3000 (L*W*H ) |
Advantage:
- We possess the upgrade and design ability with our professional technical team, your customized design could be changed into drawing.
- With advanced technology and best quality, we make sure that you can get satisfied products based on our pleasant cooperation.
* The machine also can be designed in the heat source of electricity and natural gas.
** The machine can not be used to process cotton fabric.
