Send InquiryTubular Heat Setting Machine
Tubular Heat Setting Machine Price And Quantity
- 33000.00 - 40000.00 USD ($)/Set
- 1 Set
- 33000 USD ($)/Set
Tubular Heat Setting Machine Trade Information
- Tianjin Port,China
- Letter of Credit (L/C) Western Union Letter of Credit at Sight (Sight L/C) Telegraphic Transfer (T/T)
- 50 Set Per Year
- 30 Days
- Contact us for information regarding our sample policy
- Standard Package
- Asia South America Eastern Europe Western Europe Middle East Central America Africa North America
- All India
- ISO9001,CE,SGS
Product Description
With the support of our skilled engineers, we are providing a huge series of Tubular Heat Setting Machine. It is mainly used for heat setting of tubular polyester. It makes synthetic and mixed fabric to obtain stable size with stainless steel roller. Also, it avoids the problems and difficult handling that are faced when fabric has to be processed in open width. Apart from this, we provide this Tubular Heat Setting Machine in various different specifications at nominal rates.
Introduction
- This Heat Setting Machine is used for processing of tubular chemical knitted fabric, The machine makes synthetic and mixed fabric to obtain stable size with stainless steel roller.
- The fabric is heated in the heating chamber and get cool process when getting out of machine.
- We can offer following two machines according to the width of the heating chamber: DGDX2400, DGDX3800.
- DGDX2400 machine has two work modes: double and single.When processing a narrow fabric. the double mode is adopted; When processing the wider fabric, the single mode is adopted. We can also offer you three-way mode to work.
- DGDX3800 machine adopt dual driving control mode and working mode can be designed by your requirement.
- You can customize the mercy, volume, cutting knives, and doubles.
- We can offer the following five different machine according to the normal heat source: electricity, thermal oil, natural gas.
- We make sure that we can deal with all process better in terms of energy saving and consumption,
- We will try to save cost for customer and make you get profit from this.
* The machine also can be designed in the heat source of electricity and natural gas.
** The machine can not be used to process cotton fabric.
Basic Info & Technical Data
| Main Matching Fabric | Tubular chemical fiber |
| Max. Working Width | DGDX2400 Working width: 1600mm |
| Supporting plate | Manually regulate |
| Machine Speed | 320m/min |
| Chamber Width | 2400mm |
| Power Supply | 380V·3P·50HZ |
| Main Color | Blue/Customize |
| Weight of Machine | DGDX2400 Weight: 6T |
| Drive installed capacity | DGDX2400 : 14.15kw |
| Heat-setting Type | Hot air circulating |
| Fabric Breadth control | Manually regulate |
| Driving type | Independently drive(single) |
| Temp. control type | Auto temp. Control |
| Compressed air | 0.35-0.6MPa |
| Dimension | DGDX2400 : 5700*4100*3000 (L*W*H ) |
Advantage:
- We possess the upgrade and design ability with our professional technical team, your customized design could be changed into drawing.
- With advanced technology and best quality, we make sure that you can get satisfied products based on our pleasant cooperation.
